Acoustic Adjusting Bracket 125
Excellent sound resistance. Every time.
Acoustic Adjusting Bracket is ideal for direct suspension of Premium Profiles CD 60 to solid walls and ceilings. Thanks to the integrated rubber damper at its base, the Acoustic Adjusting Bracket improves effectively sound proofing of premises by stopping the spread of impact noise and vibrations from the floor and ceiling.
Application
- For suspending a structure made of Premium Profiles CD 60 to different types of main construction (concrete, wooden grid, etc.) in areas with increased requirement for sound insulation.
Avantages
- Integrated rubber damper at the base for effective sound proofing of the premises.
- Innovative, centrally positioned rib design, for increased stability and recommended load carrying capacity (min 0.40 kN | 40 kg).
- Uniform metal thickness of 0.8 mm, for added strength.
- Easy levelling due to the shoulder positioned service holes.
- Minimized loss of useful space in the room.
Information technique
| Correspondant à EN 13964:2014 | |
| Epaisseur du métal | 0.8 mm |
| Tailles disponibles | 125 mm |
| Classement réaction au feu | A1 |
| Classement protection contre la corrosion | B |
| Charge recommandée F | 0.40 kN |
| Charge maximale admF | 0.50 kN |
Packaging
| Acoustic Adjusting Bracket 125 | 100 pièces/boîte |
| Dans des boites vertes Technogips Pro. | |
Documents
Déclaration de performances
Fiche technique
